Cell Nail Penetration

Cell nail piercing is equipment that simulates and tests hazardous situations caused by sharp objects entering battery cells. The Cell Nail Penetration Tester models and measures the reaction of cells when they are pierced by a sharp object during testing. These tests play an important role in the battery industry to ensure safe battery design and manufacturing.

Custom Manufacturing

Canatech can customize capacity and specifications according to customer requirements.

Specification

Product Specifications

📐

Volume Range

100 ~ 4,000 L

We produce it in various sizes.

🌡️

Temperature Range

20°C ~ 100°C

Offers a variety of temperature ranges

📈

Speed (Increase)

1°C ~ 10°C / min

Precise temperature control

📉

Speed (Descent)

1°C ~ 5°C / min

Stable cooling

❄️

Refrigerant Types

Water-cooled / Air-cooled

Select according to environment

💨

Airflow

Vertical airflow / horizontal airflow

Uniform temperature distribution

🔌

Computer Interface

RS-232 / RS-485 / USB Port

Data integration

📊

Controller

Up to 500 patterns / 50,000 segments

We provide diverse program configuration and systematic data management.

Safety Features & Options

Ganatech offers a variety of options that prioritize safety.

🛡️ Safety Features

Smoke detector
Flame detector
Automatic manual fire extinguishing system
Alarm buzzer
Temperature overrise prevention device
Double door locking device
Bangsan-gu
Gas exhaust duct

⚙️ Other Features

View window (fire glass, protective cover)
Shelf
Cable hole (position and size can be specified)
We are also happy to accommodate any other special requirements.

Want to learn more about our products?

Please contact us for quotation inquiries and technical consultation.
